Speroni CAM/CA 200
Pompa Bigirante

Speroni CAM / CA 200 - Double impeller pump

The Speroni CAM 200 2-impeller self-priming electric pump is equipped with a 2-pole induction electric motor . This machine offers excellent hydraulic performance and considerable pressure capacity and is ideal for lifting clean water or water mixed with chemically non-aggressive liquids in domestic and industrial environments.

The Speroni CAM 200 can suck up to 9 meters deep and also work with water mixed with gas, however by disassembling the ejector from the pump body and connecting it to the pump through a double pipe and a foot valve, it is possible to reach suction up to at 35 meters .

Download the TECHNICAL SHEET

Limits of use

• Liquid temperature: 35 ° C
• Ambient temperature: 40 ° C
• Suction height: 9 m
• Suction diameter: 1.5 "
• Delivery diameter: 1 "

Materials

• Pump course: Cast iron
• Motor support: Cast iron
• Impellers: Noryl
• Diffuser: Noryl
• Seal flange: Cast iron
• Motor shaft: Stainless steel
• Mechanical seals: Ceramic / Graphite

Motor

• Single phase 230V-50Hz
• Three-phase 230 / 400V-50Hz
• 2-pole induction electric motor (n = 2850 min-1)
• Class F insulation
• IP 55 protection
