Speroni CAM 150 BR
Self-priming Electric Pump

Speroni CAM 150 BR - Twin Impeller Self-Priming Electric Pump

The Speroni CAM 150 BR twin-impeller self-priming electric pump is ideal for domestic and industrial uses, in particular for lifting clean water, water mixed with chemically non-aggressive liquids and water mixed with gas .

Thanks to the 2-pole induction electric motor and the double impeller , the CAM 150 BR can provide excellent hydraulic performance and excellent pressure capacity, sucking up to 9 meters deep.

It is possible to reach a suction up to 35 meters by removing the ejector from the pump body and connecting it to the pump via a double pipe plus a foot valve.

The BR version, compared to the normal versions, is fitted with brass impellers.

Limits of use

• Liquid temperature: 35 ° C
• Ambient temperature: 40 ° C
• Suction height: 9 m
• Suction diameter: 1.5 "
• Delivery diameter: 1 "

Materials

• Pump course: Cast iron
• Motor support: Cast iron
• Impellers: Brass
• Diffuser: Noryl
• Seal flange: Cast iron
• Motor shaft: Stainless steel
• Mechanical seals: Ceramic / Graphite
