Accu Italia GF06180V
6V 200Ah Gel Battery for Electrical Applications

Accu Italia GF06180V - 6V 200Ah Gel Battery for Electrical Applications

The Accu Italia GF06180V is a professional, high-capacity 6V full gel battery designed for industrial plants, energy storage systems, buffer applications, and security infrastructures with continuous operation. With a nominal capacity of 180 Ah (C5) and 200 Ah (C20) , it is designed to ensure stable power supply in slow-discharge applications and intensive operating cycles, maintaining a constant operating voltage.

The immobilized thixotropic gel electrolyte technology and internal architecture with flat grid plates ensure high mechanical strength, stress resistance, and long operating life. Its dimensions (24.6 x 19.2 x 27.5 cm), weight of 31 kg, and A-Terminal connections allow for integration into professional systems requiring power continuity, safety, and total maintenance-free operation.

FUNCTIONAL SPECIFICATIONS

Professional 6V full gel battery for industrial storage

The 6V Accu Italia GF06180V battery uses high-purity gel-formed sulfuric acid , a solution that prevents electrolyte leakage and allows for safe installation even in complex technical environments. Gel technology optimizes deep-cycle management and improves electrochemical stability in long-term applications.

Capacity 180Ah C5 / 200Ah C20 with high stability

The certified capacity of 180 Ah (C5) and 200 Ah (C20) makes this high-capacity 6V full gel battery particularly suitable for backup systems and systems with constant energy demand. The internal configuration is optimized to ensure a smooth discharge curve and voltage maintenance even under prolonged loads.

Electrochemical structure with lead-calcium-tin alloy

The grid, made of a lead-calcium/tin alloy, increases corrosion resistance and improves electrical conductivity. The active material, ultra-pure lead , combined with the mixed plate technology, promotes greater energy efficiency and extended cyclic life in professional environments.

Highly reliable duroplastic-microporous separator

The microporous duroplastic separator ensures uniform insulation between the plates and even distribution of the gelled electrolyte, reducing the risk of internal short circuits. This technical solution increases the operational safety of the professional battery for industrial systems .

Structural format with A-Terminal terminals

The 24.6 x 19.2 x 27.5 cm dimensions and 31 kg weight provide solidity in fixed installations and stationary storage systems. A-Terminal connections ensure stable and mechanically robust connections, guaranteeing electrical continuity and reliability on high-performance cabling.

Why choose a Gel battery?

• Reliable recovery even after deep discharges , without the need for immediate recharging
• Designed for daily use with repeated cycles
• Stable performance over long duration discharges
• Good operation in high temperature environments
• Immobilized electrolyte that eliminates stratification
• Low self-discharge and less maintenance required
• Positive plate protection for longer cycle life
• High charge acceptance due to low internal resistance
• High resistance to water loss with proper refill management
• Highly stable polymer separator , resistant to mechanical stress and short circuits

Areas of Use

• Caravans and Campers
• Floor cleaning machines
• Solar systems
• UPS (Uninterruptible Power Supply)
• Electric vehicles
• Nautical

Characteristics

• Full Gel lead-acid battery
• Nominal voltage 6V
• Capacity 180 Ah (C5) / 200 Ah (C20)
• 700 charge cycles for intensive use
• Poli A-Terminal
• Dimensions 24.6 x 19.2 x 27.5 cm
• Operating temperature from -20°C to +50°C
• High purity materials
• Duroplastic-microporous separators

Standard Equipment

• A-Terminal

Optional Equipment

• Pair of M6 conical pole adapters - code 90000012
