HEAD FOR WASHING BARRELS AND TANKS Electric or Pneumatic Diameter 45
M63E - Rotating Head for Tank Washing - Flow rate 15-50 liters / min - Also in ATEX pneumatic version
PA M63E - Rotating head
Cleaning barrels and tanks
Rotating Head - Also in ATEX version
Self-propelled rotating head for washing barrels and tanks with high flow rate (up to 50 liters per minute).
Also available in version with head Φ50 and 40 liters per minute.
The washing cycle guarantees the total orbital coverage of the interiors with minimum bulk.
It is a sophisticated washing system where high impact jets move slowly with a combined movement and rotate around a vertical and a horizontal axis.
The mechanism is designed so that the pressure jets cover different paths at each turn, so as not to leave any part of the surface to be washed untreated.
Stainless steel construction and low voltage or pneumatic power supply (ATEX certification) for the highest level of safety.
Functional characteristics
The Rotating Head is built to work with water up to 90 ° C, with the addition of general purpose detergents or disinfectants.
The rotating HEAD must be connected to a pressure circuit, generally pressure washers and the like, equipped with all safety and control devices (such as safety valves, regulation valves, etc.)
The HEAD must be firmly anchored to the mouth of the tank or to a special support, the nozzles must be located if possible in the center of the tank and equidistant from the walls.
The nozzles (two in number) of the high pressure washing type with straight jet must be suitable for the flow rate and pressure at which it is intended to operate.
The HEAD is rotated by the electric motor reducer at the upper end, powered at low voltage (24V.cc) or with a pneumatic compressed air system (ATEX) for total safety.
The liquid sent from the system to the head must be filtered to prevent foreign bodies from entering, causing malfunction and consequently more frequent maintenance interventions.
MAINTENANCE: after normal use, wash the head inside by feeding it with clean water without additives.
Rod Length | Supply |
---|---|
915 mm rigid - Model M63E | 24 Volt approx |
915 mm rigid / 650 mm Flexible - Model M63PA | ATEX tire |
Technical data
Entry | AR1 A M22 |
Nominal pressure | 140 bar |
Permitted pressure | 160 bar |
Nominal flow rate | 10/25 L / min |
Nominal temperature | 90 ° C |
Electric motor | 24V - 30 W |
Overall dimensions Ø min. | 45 mm |
Nozzle type | 4 x M4 |
Technical data
Entry | AR1 A M22 |
Nominal pressure | 140 bar |
Permitted pressure | 160 bar |
Nominal flow rate | 10/25 L / min |
Nominal temperature | 90 ° C |
Electric motor | 24V - 30 W |
Overall dimensions Ø min. | 45 mm |
Nozzle type | 4 x M4 |
