HEAD FOR WASHING BARRELS WITH SUCTION

PA M28E - Rotating head
Cleaning Barrels, Barriques, Tank

Rotating Head With Suction

Rotating head with liquid suction system for cleaning barrels, barriques, tanks and other containers with limited access.

The low-flow pumphead with high pressure and impact force. Cleaning guarantees total coverage of the interior with minimum space.
It is a sophisticated washing system where high impact jets move slowly with a combined movement and rotate around a vertical and a horizontal axis.
The mechanism is designed so that the pressure jets cover different paths at each turn, so as not to leave any part of the surface to be washed untreated.

Stainless steel construction and low voltage power supply for the highest level of safety.

Functional characteristics

The Rotating Head with Suction is built to work with water up to 90 ° C, with the addition of general purpose detergents or disinfectants.

The rotating HEAD must be connected to a pressure circuit, generally pressure washers and the like, equipped with all safety and control devices (such as safety valves, regulation valves, etc.)

The HEAD must be firmly anchored to the mouth of the tank or to a special support, the nozzles must be located if possible in the center of the tank and equidistant from the walls.

The nozzles (two in number) of the high pressure washing type with straight jet must be suitable for the flow rate and pressure at which it is intended to operate.

The HEAD is rotated by the electric motor reducer at the upper end, powered at low voltage (12V.cc) for total safety.

The liquid sent from the system to the head must be filtered to prevent foreign bodies from entering, causing malfunction and consequently more frequent maintenance interventions.

MAINTENANCE: after normal use, wash the head inside by feeding it with clean water without additives.
