Docma SF75 XX
Vertical log splitter
Originale Docma - Made in Italy
230V/400V - 3 HP, 4 HP - 2,2/3 kW - 7 T
€1,266.00
€1,037.70 tax excl.
Warranty 2
years
Shipped on Pallet
Docma SF75 XX - Single-phase and three-phase log splitter
Docma 910060 is a SF75 XX wood splitter ideal for small deforestation and domestic woodcutters. Belonging to the Cutmac basic line, Docma 910060 log splitter model SF75 220 XX has a single-phase 230V power connection, while the three-phase 400 V Docma log splitter SF75 380 XX.
Machinery Made in Italy Docma 910060 is a solid and robust log splitter , capable of absorbing the effort of cutting logs of medium diameter. The SF75 220 XX and SF75 380 XX log splitters develop vertically, with rubber wheels to facilitate transport, a rear handle and side grips for inserting and blocking the pieces to be split.
Functional specifications
Log splitter SF75 220 XX single-phase
With a 230 V electric motor, this electric log splitter has a power of 2.2 kW and 3 HP with a single pump . This logging machine has a push force of 7 tons .
Log splitter SF75 380 XX three-phase
With a 400 V three-phase motor, this wood splitter for domestic use has a power of 3 kW and 4 HP with a single pump and has a thrust force of 7.5 tons .
Docma SF75 XX log splitter features
With a cylinder stroke of 500 mm and a cutting height of 545 mm , this vertical log splitter has an adjustable column and requires 7 L of oil .
The indicative dimensions are 60 x 56 x 110 cm , indicative weight 102 kg .
Models available
- Single-phase - SF75 220 XX
- Three-phase - SF75 380 XX
Characteristics
- Vertical log splitter for domestic use
- Single-phase / three-phase version
- Solid and robust
- Rubber wheels, rear handle and side handles
- Cylinder stroke 500 mm
- Cutting height 545 mm
- Adjustable column
Technical data
| Model | SF75 220XX | SF75 380 XX |
| Code | 910060 | 910077 |
| Power Supply | 230V | 400V |
| Power | 2.2 kW | 3 kW |
| Horses | 3 HP | 4hp |
| Pump type | Single | Single |
| Cylinder Stroke | 500mm | 500mm |
| Cutting height | 545mm | 545mm |
| Force Push | 7 tons | 7 tons |
| Quantity Oil | 7 L | 7 L |
| Column race | Adjustable | Adjustable |
| Indicative dimensions | 60 x 56 x 110cm | 60 x 56 x 110cm |
| Weight | 102kg | 102kg |
