Annovi Reverberi AR 5850 - Compact Hot Water Pressure Washer
Annovi Reverberi AR 5850 , a professional-quality hot water pressure washer with a 1450 rpm single-phase induction motor with thermal protection and a brass head . The pressure washer has a solid and compact structure , equipped with large rubber wheels for movement and convenient supports for storing the lance and hose. The machine is built using top-quality components and features a high-performance piston pump with a connecting rod and crank system and an automatic by-pass valve with zero pressure in the pump head.
The AR 5850 pressure washer can provide hot water up to 150°C thanks to its vertical stainless steel boiler . The boiler is fueled by diesel and uses a spiral burner cooling system powered by an independent electric motor. It features a double coil and a refractory concrete base . The high water temperature is ideal for removing stubborn dirt and encrustations.
The machine is equipped with a series of features to ensure safe and efficient operation: there are water and diesel filters , a safety pressure switch to ensure the boiler shuts down in the event of a water shortage, and a delay card to shut it down. There is also a thermostat for temperature regulation and a pressure regulation system.
The Annovi Reverberi AR 5850 guarantees great autonomy thanks to the 8 L diesel tank with drain plug and offers a built-in detergent suction system.
Self-priming function
A self-priming pump is designed to draw water from an external source (such as a tank, drum, or container) without requiring water to be forced into the pump by initial pressure. This makes the pressure washer more versatile, allowing it to operate even without a direct connection to a pressurized water supply, such as when a tap isn't available, or to use alternative water sources such as tanks and wells.
Technical specifications
- Hot water
- Induction motor
- Connecting rod pump
- IPX5-S1 water resistance
- Brass head
- Total Stop System
HRC_EM pump
- 3-piston ceramic pump with connecting rod and crank system and brass pump head
- Automatic safety valve that ensures rapid pressure relief in the pump head
- Single-phase induction electric motor with thermal protection;
- Remote pressure washer total shutdown system;
- Water suction from tank with self-priming function.
Annovi Reverberi AR 5870 Pump Detail
With pump detail.
Characteristics
- Compact structure
- Transport wheels
- Lance and hose supports
- Hot water up to 150°C
- Piston pump with brass head
- Automatic bypass valve
- Safety pressure switch
- Vertical stainless steel boiler
- Boiler shutdown delay card
- Pressure regulation
- 8 L diesel tank with drain plug
- Thermostat
- Detergent suction
- Water filter and diesel filter
- 5m electric cable
Equipment
- Professional pistol
- Professional steel lance
- Nozzle
- 8 m high pressure hose
