Tecnogen H8000TELX
Three-Phase Generator
Electric Start with ATS

Tecnogen H8000TELX - Three-Phase Electric Start Generator

The Tecnogen H8000TELX is a professional three-phase petrol generator designed for industrial, agricultural and construction applications. Equipped with a 389 cm³ Honda GX390 engine and operating at 3000 RPM , it delivers up to 7.5 kVA at 400V and 3.8 kVA at 230V. The electric start and optional AVR preparation ensure operational convenience and power stability.

Available models

• H8000TELX with standard frame
• H8000TELX with ATS panel only

TECHNICAL SPECIFICATIONS

The Tecnogen H8000TELX generator is equipped with a 389 cm³ Honda GX390 OHV single-cylinder petrol engine with 12V electric start . The maximum power is 7.5 kVA / 6.0 kW three-phase 400V and 3.8 kVA / 3.1 kW single-phase 230V . Consumption at 75% load is 1.9 L/h with a 20 L fuel tank . The unit is equipped with thermal protection , low oil level control , anti-vibration mounts , tubular frame and exhaust silencer . The AVR configuration is available on request.

FUNCTIONAL SPECIFICATIONS

Honda GX390 engine

The Honda GX390 engine with OHV distribution and CDI digital ignition ensures reliability, low fuel consumption and low vibrations in continuous professional use.

Professional Three-Phase Generator

The 400V three-phase configuration allows the powering of industrial machinery and professional equipment with high absorption with stable and continuous delivery.

Electric Start

The electric start with 12V battery optimizes start-up speed and operational convenience on construction sites and in industrial environments.

Integrated Protections

The unit integrates thermal protection for sockets and an engine shutdown system for low oil level , improving safety and operational reliability.

Anti-Vibration Structure

Tubular frame , anti-vibration supports and lifting hook ensure structural strength and ease of handling.

Characteristics

• Professional petrol generator
• 400V three-phase generator set
• Maximum power at 230V 3.8 kVA / 3.1 kW
• Maximum power at 400V 7.5 kVA / 6.0 kW
• Honda GX390 single-cylinder OHV 389 cm³ engine
• Engine speed 3000 RPM
• Electric start
• Fuel consumption 1.9 L/h at 75% load
• 20 L petrol tank
• Low engine oil level protection system
• Thermal or magnetothermal protection on sockets
• Tubular frame with anti-vibration supports
• Integrated exhaust silencer
• AVR regulator provision on request
• Industrial assembly made in Italy
