Trotec DH 310 BX ES inox
Industrial Dehumidifier 500L/24h

Trotec DH 310 BX ES inox - Industrial Dehumidifier 500L/24h

The Trotec DH 310 BX ES is an industrial dehumidifier made of AISI 316 stainless steel designed for environments with special hygiene requirements and industrial applications requiring precise humidity control. With a dehumidification capacity of 500 L/24h and an air flow rate of 4600 m³/h, it guarantees high performance even at low temperatures, ensuring continuous and reliable operation. The device is equipped with an integrated condensate pump , a silent scroll compressor and a self-regulating EC radial fan , which optimise energy efficiency with a consumption of only 6.9 kW . Thanks to the hot gas bypass defrosting system, defrosting phases are rapid and minimise downtime. The Trotec DH 310 BX ES is easy to install on the floor, wall or ceiling and can be connected to existing duct systems. Its robust construction makes it ideal for warehouses, production plants, the food industry and sensitive environments, guaranteeing protection against mould, condensation and corrosion.

For environments with special hygiene requirements
With integrated condensation pump and hot gas defrosting

Functional specifications

Stainless steel dehumidifier

The Trotec DH 310 BX ES (cod. 1125000176) is a high-end industrial dehumidifier designed for environments with high hygiene requirements. The AISI 316 stainless steel casing ensures resistance to corrosion, chlorides, and aggressive chemicals such as sulfuric acid and iodides. With a dehumidification capacity of 500 L/24h and an air flow rate of 4600 m³/h , it guarantees continuous and reliable dehumidification even under extreme conditions.

Continuous operation and energy efficiency

The Trotec DH 310 BX ES uses a quiet scroll compressor combined with a self-regulating EC radial fan , ensuring constant pressure without pulsations. The hot gas bypass defrosting system allows for rapid defrosting phases, improving performance in cold or unheated environments. The coefficient of performance (COP) of 3 generates 3 kW of heat for every kW consumed, optimizing energy consumption and reducing operating costs.

Optional

Available upon request:

• Heat exchanger with KTL coating
• High pressure fan
• Defrost below 0°C

Scope of use

Ineffective humidity control can cause significant problems in production processes, inventories, and stored goods, causing rust, material decay, loss of quality, and mold growth. The Trotec DH 310 BX ES, thanks to its robust construction and high dehumidification capacity, ensures a dry and stable environment, protecting materials and equipment in numerous industrial settings. It is ideal for:

• Keep production plants and warehouses dry
• Protect machine rooms and storage rooms from corrosion
• Dehumidify plumbing systems and pumping stations
• Prevent corrosion in electrical panels, boiler systems, piping systems
• Regulate humidity in server rooms and control rooms
• Regulating humidity in the food industry, in dairies
• Regulating humidity in the naval or cargo sector

Characteristics

• • • Dehumidification 500 L/24 h
    • Air flow 4600 m³/h
    • Stainless Steel Casing
    • Integrated Condensate Pump
    • Automatic Gas Defrost
    • Silent and Efficient Scroll Compressor
    • Automatic Operation
    • Continuously self-regulating EC fan
    • Flexible installation (Floor/Wall/Ceiling)
