Pramac VT-Solar Manual
Lighting Tower 6.5 m
with Solar Panels
MPN: VT-SOLARMANUAL
6.5m - 4 x 100W
Generator sold separately
2100 m²
Warranty 2 years
Shipped on Pallet
Pramac VT-Solar Manual - Lighting Tower with Solar Panels
The battery-powered Pramac VT-Solar Manual Lighting Tower is the ecological solution for night work or in difficult visibility conditions , allowing illumination of up to 2100 m² . The manual lifting telescopic pole can reach 6.5 m . The easy-to-use control panel and the possibility of charging via an external power source make this light tower simple to use and versatile .
Technical specifications
The battery-powered Pramac VT-Solar Manual Lighting Tower has an integrated AGM battery pack with the possibility of recharging either from the internal inverter powered by the 3x330 Wp of the supplied solar panels , from an external power source or directly from the electricity grid . With a charging time of 8 hours , the VT-Solar Manual Light Tower lasts approximately 17 hours with all LEDs turned on . The G4 LED lamps of 100W each are designed by Generac Mobile and have adjustable light output from 25% to 100% .
The 4 stabilizers make the Light Tower stable, while the 3 wheels and the tow hook offer easy transportability of the machine.
Control Panel
- Battery monitoring system
- Low battery voltage alarm
- Fuse for direct current protection
- Inverter alarm
- Hour meter
- RCD-MCB switches
- Electrical mains switch
- Headlight switches
- Main system On/Off button. Solar panel switch
- Digital timer (optional)
- Twilight sensor (optional)
- Selector for manual mode / digital timer / twilight sensor (optional)
- Advanced digital controller (optional)
Characteristics
- Multi LED Light Tower
- Manual lifting telescopic rod
- Telescopic rod height 6.5 m
- Adjustable light power 25% ÷ 100%
- Equipped with integrated AGM battery pack
- Rechargeable with 3x330 Wp solar panels, mains electricity or external power source
- Easy-to-use control panel
- Differential protection for each panel switch
Technical data
| Voltage | 230V |
| Lighthouses | G4 LED 4x100W |
| Lumens | 60000 lm |
| Max. Illumination | 2100 m² |
| Maximum Extension | 6.5 m |
| Lift | Manual |
| Rotation | 340° |
| Stability in the Wind | up to 80 km/h |
| Generator | Not included |
| Power Supply | Drums |
| Battery Pack Autonomy | 5pm |
| Battery Recharge Time | 8 hours |
| Solar Panel Power | 3 x 330 Wp |
| Tilting Solar Panels | min. 0° / max. 35° |
| CEE 16A power plug | YES |
| Multipin Power Plug | YES |
| Stabilizers | 4 |
| Open dimensions | 352 x 306 x 650 cm |
| Dry weight | 1000kg |
Technical data
| Voltage | 230V |
| Lighthouses | G4 LED 4x100W |
| Lumens | 60000 lm |
| Max. Illumination | 2100 m² |
| Maximum Extension | 6.5 m |
| Lift | Manual |
| Rotation | 340° |
| Stability in the Wind | up to 80 km/h |
| Generator | Not included |
| Power Supply | Drums |
| Battery Pack Autonomy | 5pm |
| Battery Recharge Time | 8 hours |
| Solar Panel Power | 3 x 330 Wp |
| Tilting Solar Panels | min. 0° / max. 35° |
| CEE 16A power plug | YES |
| Multipin Power Plug | YES |
| Stabilizers | 4 |
| Open dimensions | 352 x 306 x 650 cm |
| Dry weight | 1000kg |
