CGM BE
Multi LED 230V Lighting Tower
Lighting up to 5000 m²
Hydraulic lifting up to 8.5 m
4 ÷6 x 160 ÷320 W / 3000 ÷ 5000 m²
Generator sold separately
CGM BE Multi LED Lighting Tower with 8.5 m Telescopic Pole
The CGM BE 230V Lighting Towers are available in 3 different models to choose from based on your lighting needs. Equipped with a 16A 3P power socket and plug to allow the series connection of multiple units to the same energy source.
The telescopic pole has a hydraulic lifting system that reaches 8.5 m in height and a rotation of 359° , while the movement of the headlights is manual . This machine can tolerate adverse weather conditions , with a maximum wind resistance of 110 km/h .

Models Available
Model BE4-320L
The CGM BE4-320L model has 4 320W LED headlights of 41550 lm (Lumen) each and a lightable area of 5000 m² @ 5 lux .
Model BE6-160L
The CGM BE6-160L model has 6 160W LED headlights of 20350 lm (Lumen) each and a lightable area of 4200 m² @ 5 lux .
Model BE4-160L
The CGM BE4-160L model has 4 160W LED headlights of 20350 lm (Lumen) each and a lightable area of 3000 m² @ 5 lux .

Functional Specifications
The CGM BE Lighting Towers are the ideal solution for night work or in difficult visibility conditions , allowing you to illuminate up to 5000 m² . LED lamps work with high energy efficiency . Available in 3 different models, you can choose the version with 4 320W LED lights, 4 160W LED lights or 6 160W LED lights.
Technical specifications
The BE Lighting Towers have a telescopic pole that can be extended up to 8.5 m in height with motorized hydraulic lifting . Wind stability up to 110 km/h is guaranteed by the presence of 4 stabilizers . The CGM BE models, thanks to their powerful headlights, can illuminate up to 5000 m².

Fields of Application
- Gas, oil and mining extraction sites
- Buildings
- Emergency
- Military applications
- Special events
- Hard to reach areas
Watch the video
Characteristics
- Multi LED Light Tower
- Motorized hydraulic telescopic rod
- Manual movement of the headlights
- Telescopic pole height 8.5 m
- Input plug and output socket 16A 230V
Technical data
| Model | BE4-32L | BE6-160L | BE4-160L |
| Voltage | 230V | 230V | 230V |
| Lighthouses | 4 x 320W LEDs | LED 6 x 160W | 4 x 160W LEDs |
| Lumens | 41550 lm | 20350 lm | 20350 lm |
| Maximum Extension | 8.5 m | 8.5 m | 8.5 m |
| Lift | Hydraulic | Hydraulic | Hydraulic |
| Max. Illumination | 5000 m² | 4200 m² | 3000 m² |
| Stabilizers | 4 | 4 | 4 |
| Generator | Not included | Not included | Not included |
| Open dimensions | 120 x 850 x 100 cm | 120 x 850 x 100 cm | 120 x 850 x 100 cm |
| Weight | 550kg | 550kg | 550kg |
