Annovi Reverberi 787 Dual Pro - Professional Cold Water Pressure Washer 200 bar
The Annovi Reverberi 787 Dual Pro is a professional cold water pressure washer designed for artisans, industrial operators, and professionals who require high power and operational continuity . The combination of a three-phase induction electric motor and a 3-piston HRC ceramic piston pump allows for a maximum pressure of 200 bar with a flow rate of up to 840 L/h , ensuring high dirt removal capacity even in the most demanding applications. The Total Stop System V DPA allows the pressure washer to be stopped remotely, limiting consumption, reducing pump wear, and improving safety during use.
Designed to handle intensive work cycles, the Annovi Reverberi 7 Series combines structural solidity and flexibility of use. The steel load-bearing frame , 220 mm wheels with rubber tread , and ergonomic layout allow the machine to be used in both vertical and horizontal configurations, facilitating movement even in complex operating environments. Made in Italy production ensures long-lasting reliability and consistent performance, making the 787 Dual Pro a high-end professional solution for those seeking uncompromising quality.
Hose reel NOT INCLUDED.
TECHNICAL SPECIFICATIONS
The Annovi Reverberi 787 Heavy Pro is powered by a three-phase 400V power supply with a power consumption of 5 kW , designed to tackle intensive industrial applications. The induction electric motor develops 6.1 HP and 4.5 kW with a speed of 1450 RPM , ensuring operational continuity and stable performance even during prolonged work cycles. The HRC 3-piston ceramic pump, with connecting rod-crank system and brass head , is designed to resist wear and maintain high performance under constant pressure. The machine falls within protection class I and is equipped with an IPX5 protection rating , ensuring safety in professional environments.
During use, the pressure washer delivers a maximum pressure of 200 bar with a nominal pressure of 180 bar and a flow rate of up to 840 L/h , ensuring high cleaning capacity. The timed Total Stop , integrated pressure gauge , and pressure regulation allow the jet to be adapted to different operational applications, while the two-wheel trolley with handle and lifting points on the frame simplify transport and positioning. The Self Priming function allows water to be drawn from external tanks even in the absence of a direct connection to the water mains, increasing autonomy and flexibility at work.
- Induction motor
- Brass head
- Connecting rod pump
- Maximum water temperature 60°C
- IPX-S1 water resistance
- Bypass
- Self-priming function
- Total Stop System Timed
FUNCTIONAL SPECIFICATIONS
Total Stop System V DPA
The DPA Total Stop System V allows you to completely stop the machine when the gun is not in use. This system reduces energy consumption , limits pump wear , and increases operator safety , making this pressure washer perfect for prolonged professional use.
HRC 3-piston ceramic pump
The HRC pump is designed for reliability and durability. The three ceramic pistons , brass head , and connecting rod system maintain stable pressure even during intensive work, offering consistent performance and optimizing efficiency in any professional operation.
Pressure-regulating gun
The gun with pressure regulator and three-position OFF/TSS/bypass selector allows you to adjust the spray pattern to suit your needs. Whether you're spraying delicate surfaces or stubborn dirt, precise control improves efficiency, reduces the risk of damage, and increases productivity.
Load-bearing frame and mobility
The steel frame with lifting points , the two-wheeled Ø 220 mm trolley, and the ergonomic handle ensure quick and easy movement. The removable front panel allows quick access to the motor and pump for maintenance, reducing downtime and simplifying daily management.
Safety and easy maintenance
The 787 Dual Pro features an automatic safety valve with pressure relief , oil level indicator, and oil drain, ensuring maximum operator safety and ease of maintenance. This design reduces the risk of overload and ensures the longevity of the pump and motor.
Self-priming function
A self-priming pump is designed to draw water from an external source (such as a tank, drum, or container) without requiring water to be forced into the pump by initial pressure. This makes the pressure washer more versatile, allowing it to operate even without a direct connection to a pressurized water supply, such as when a tap isn't available, or to use alternative water sources such as tanks and wells.
HRC pump
- 3-piston ceramic pump with connecting rod and crank system, brass pump head
- Automatic safety valve with pressure relief in the pump head
- Single-phase induction electric motor with thermal protection
- Remote Pressure Washer Total Shut Off System V DPA
- Water suction from tank with self-priming function
Characteristics
- Professional cold water pressure washer
- 400V three-phase power supply
- Maximum power 5 kW
- Maximum pressure 200 bar
- Maximum flow rate 840 L/h
- Engine speed 1450 RPM
- Self-priming function
- Total Stop System V DPA and remote complete stop
- Steel load-bearing frame
- Gun with pressure regulator
- Made in Italy
Standard Equipment
- AR 528 DPS pistol, M22x1.5 M entry, M22x1.5 F exit - code 47768
- Lance inlet M22x1.5 M outlet 1/4 NPT F - code 50690
- Nozzle 1/4 NPT M - code 3082
- 10 m flexible hose, M22x1.5 F inlet, M22x1.5 F outlet - code 3083550
