Novamach NEEN Q2-B
1500 Kg Electric Pallet Truck
MPN: NEENQ
Height 8÷20.5 cm
Capacity 1500 kg
Dimensions 54 x 153 x 8 cm
€1,999.00
€1,638.52 tax excl.
Warranty 5
years
Shipped on Pallet
Novamach NEEN Q2-B - 1500 Kg Electric Pallet Truck
The Novamach NEEN Q2-B electric pallet truck is designed for professional handling of loads up to 1500 kg , powered by a 24V 20Ah lithium-ion battery . The compact and lightweight design makes it ideal for operating in warehouses and confined spaces, while the robust structure guarantees integrity and reliability even under intensive use .
Technical specifications
The Novamach NEEN Q2-B is a pedestrian pallet truck with electric traction and lift , equipped with polyurethane rollers and wheels to ensure smooth operation, strength and long life. The forks have a minimum height of 8 cm and a maximum raised height of 20.5 cm and a width of 54 cm. The overall length of the pallet truck is 154.3 cm , while the overall weight is 125 kg , with an external charger for efficient energy management.
Functional specifications
Capacity 1500 kg
Novamach NEEN Q2-B handles loads up to 1500 kg with safety and stability, ideal for intensive logistics operations and industrial handling.
Complete electric movement
Thanks to electric traction and lifting , the pallet truck reduces the operator's manual effort, optimising time and productivity in loading and unloading activities.
Polyurethane rollers and wheels
The polyurethane wheels and rollers ensure smooth running, mechanical resistance and sound insulation, guaranteeing long life even with frequent use.
Electromagnetic brake and reliable autonomy
The electromagnetic service brake allows for precise and safe stops, while the lithium-ion battery ensures constant autonomy and rapid charging via an external charger.
Characteristics
- 24V battery-powered pallet truck
- Height from 80 to 205 mm
- Capacity 1500 kg
- Polyurethane rollers
- Polyurethane wheels
- Dimensions 154.3 x 54 cm
- Weight 125 kg
Technical Data
| Code | NEEN Q2-B |
| Traction | Drums |
| Translation | Electric |
| Lifting | Electric |
| Type | Man down |
| Flow rate | 1500 kg |
| Load Center Distance | 60 cm |
| Distance between machine body and forks | 94.7 cm |
| Wheelbase | 118.9 cm |
| Load Axle/Full Load | 626÷1001 Kg |
| Load/Empty Axis | 99÷28 Kg |
| Wheels | Polyurethane |
| Wheel Size | 21 x 7.5 cm |
| Roller Size | 8 x 9.3 cm |
| Pivoting Wheel | 8 x 3 cm |
| Distance between the Center of the Pivoting Wheels | 43 cm |
| Distance between the centre of the rollers | 38 cm |
| Lifting Height | 20.5 cm |
| Handle Height Guide Position Minimum/Maximum | 65.5÷116 cm |
| Minimum Fork Height | 8 cm |
| Total Length | 154.3 cm |
| Fork Body Distance | 39.3 cm |
| Total Length | 54 cm |
| Fork Size | 50/160/115 cm |
| External Fork Width | 54 cm |
| Raised Fork Height | 3 cm |
| Pallet Aisle Width 800*1200 | 201.3 cm |
| Turning Radius | 134 cm |
| Loading/Unloading Advance Speed | 4.3÷4.9 km/s |
| Lifting Speed Loading/Unloading | 0.015÷0.022 m/s |
| Loading/Unloading Descent Speed | 0.05÷0.0026 m/s |
| Maximum Load/Unload Slope | 6÷16% |
| Service Brake | Electromagnetic |
| Traction Motor S2 60 Min. | 0.75 kW |
| S3 Lifting Motor 15% | 0.5 kW |
| Battery Weight | 6.5 kg |
| Battery Voltage | 24V |
| Motor | A.D |
| Energy Consumption | 0.25 kWh/h |
| Noise | > 70 dB(A) |
| Battery charger | External |
| Dimensions | 154.3 x 54 cm |
| Weight | 125 kg |
Technical Data
| Code | NEEN Q2-B |
| Traction | Drums |
| Translation | Electric |
| Lifting | Electric |
| Type | Man down |
| Flow rate | 1500 kg |
| Load Center Distance | 60 cm |
| Distance between machine body and forks | 94.7 cm |
| Wheelbase | 118.9 cm |
| Load Axle/Full Load | 626÷1001 Kg |
| Load/Empty Axis | 99÷28 Kg |
| Wheels | Polyurethane |
| Wheel Size | 21 x 7.5 cm |
| Roller Size | 8 x 9.3 cm |
| Pivoting Wheel | 8 x 3 cm |
| Distance between the Center of the Pivoting Wheels | 43 cm |
| Distance between the centre of the rollers | 38 cm |
| Lifting Height | 20.5 cm |
| Handle Height Guide Position Minimum/Maximum | 65.5÷116 cm |
| Minimum Fork Height | 8 cm |
| Total Length | 154.3 cm |
| Fork Body Distance | 39.3 cm |
| Total Length | 54 cm |
| Fork Size | 50/160/115 cm |
| External Fork Width | 54 cm |
| Raised Fork Height | 3 cm |
| Pallet Aisle Width 800*1200 | 201.3 cm |
| Turning Radius | 134 cm |
| Loading/Unloading Advance Speed | 4.3÷4.9 km/s |
| Lifting Speed Loading/Unloading | 0.015÷0.022 m/s |
| Loading/Unloading Descent Speed | 0.05÷0.0026 m/s |
| Maximum Load/Unload Slope | 6÷16% |
| Service Brake | Electromagnetic |
| Traction Motor S2 60 Min. | 0.75 kW |
| S3 Lifting Motor 15% | 0.5 kW |
| Battery Weight | 6.5 kg |
| Battery Voltage | 24V |
| Motor | A.D |
| Energy Consumption | 0.25 kWh/h |
| Noise | > 70 dB(A) |
| Battery charger | External |
| Dimensions | 154.3 x 54 cm |
| Weight | 125 kg |
