Telwin Technology Tig 202
AC/DC Inverter Welding Machine
with accessories

Telwin Technology Tig 202 cod. 816244 - Inverter TIG / MMA Welding Machine

Telwin Technology Tig 202 cod. 816244 It is a TIG inverter welder ( HF or LIFT high frequency ignition), PULSED TIG (Pulse and Easy Pulse) and MMA in direct and alternating current ( AC/DC ). The Technology Tig welder can be used with different types of materials such as stainless steel, titanium, copper, nickel and their alloys, aluminum, magnesium and their alloys .

Functional Specifications

Telwin Technology TIG 202 is equipped with an LCD screen that significantly improves and simplifies the setting of welding parameters and allows the saving of customized programs .
Among the settings that can be adjusted on the welding curve we have:

• electrode preheating
• initial/final current
• Pointing time
• pre/post gas
• current start/end ramp
• DC/AC balance
• square wave frequency

Electrode welding is optimal when used with basic electrodes and in positional welding .

This inverter welder is equipped with a cooling system with a dedicated air tunnel which protects it from dust and dirt, ensuring great reliability over time.

Telwin Technology TIG 202 ensures optimal performance even in the event of undervoltages (up to -15%) and overvoltages (up to +15%) as well as having thermostatic and overcurrent protection.

TYPES OF WELDING POSSIBLE WITH Telwin Technology Tig

• MMA : also called coated electrode welding, it is certainly the most widespread welding method in non-professional environments or in processes that do not require particular qualitative and productive performance. This type of welding machines are simpler to use even if they give less precise results from an aesthetic point of view compared to other types of welding.
• TIG : TIG welding requires a lower voltage and therefore absorbs less, it becomes cheaper and is aesthetically the most beautiful. TIG welding has a so-called coin shape due to the circular shapes it produces and is more resistant therefore it is usually used in visible elements and on processes that require precision.

Telwin Technology Tig Protections

• Thermostatic
• Overvoltage
• Undervoltage
• Overcurrent

Characteristics

• Programmable in 10 customizable programs
• Adjustment of multiple welding curve parameters
• Thinspot and AC/DC Mix functions
• Start (HF/LIFT) at optimized minimum current
• Remote control provision
• Compatibility with PRO flashlights
• Direct current and pulsed current operation (MMA PULSE)
• Hot start, arc force adjustments
• Anti-stick protection
• VRD Device

Standard equipment

• Argon cylinder adapter - code 432036
• Pressure reducer 2 manometers 12 L/min - code 722119
• Cable 25 mmq 3 m Atlas 50 mmq - code 713504
• Toledo 300 ground clamp - code 712231
