Genmac Land TR 65-80-93
Cardan Generator
4 Poles AVR

Genmac Land - 4 pole Cardan Generator 144÷285 HP with Voltage Regulator

The Genmac Land generator is a cardan generator designed for agricultural use. Generator which, combined with a tractor for agricultural use , uses the power of the tractor to generate electricity.

The Genmac Land 4-pole AVR cardan generator can be used in agricultural activities where energy is required to power electrical equipment , such as irrigation pumps , agricultural machinery or lighting .

Perfect for agricultural companies , work in wooded or forestry areas , greenery maintenance , livestock farms and for users who own a tractor and want to exploit the power generated by the vehicle to provide energy. and power electric tools, in areas where it is not possible to access the terrestrial electricity grid or in the event of an emergency/blackout.

Functional specifications

Land TR65: 4-pole cardan generator AVR 77 HP

The Genmac Land TR65 cardan generator has a 4-pole alternator with AVR. This cardan generator has 1500 rpm, with tractor power 202 HP , oil capacity 0.5L. The nominal power is 21.7 kW (kVA), with three-phase nominal power 65 kW (kVA).

Land TR80: 4-pole cardan generator AVR 92 HP

The Genmac Land TR80 cardan generator has a 4-pole alternator with AVR. This cardan generator has 1500 rpm, with tractor power 247 HP , oil capacity 0.5L. The nominal single-phase power is 26.7 kW (kVA), with three-phase power 80kW (kVA).

Land TR93: 4 pole AVR generator for 285 HP tractor

The Genmac Land TR93 cardan generator has a 4-pole alternator with AVR. This cardan generator has 1500 rpm, with tractor power 285 HP , oil capacity 0.5L. The nominal single-phase power is 31kW (kVA), with three-phase power 93 kW (kVA).

TR65 - TR80 - TR93 sockets

• 1 x Schuko
• 1 x CEE 32A 230V
• 1 x CEE 125A 400V

Main features

• For tractors with power from 202 to 285 HP
• Single-phase and three-phase output current
• Switch magnetermic
• Differential Switch
• Voltmeter
• Ammeter
• Frequency meter
• Oil capacity 0.5 L
• Speed 400 RPM
• Hour meter standard on models

Operation of the cardan generator

However, it is important to choose a cardan generator with cardan connection suitable for the tractor . A cardan-driven generator set is composed of a frame on which an alternator is positioned which can be connected to the tractor by a special speed multiplier on one side. On the opposite side it is equipped with an electrical panel with power sockets.

The cardan generator sets are operated with a cardan coupling , thanks to the action of the PTO power take-off . (Power Take Off) of a tractor for agricultural use, through direct coupling to the cardan . Everything is fixed on a metal frame to protect the alternator and allow for more comfortable use.

The operation of a cardan generator can be summarized in these points:

• Connection to the tractor : The cardan generator is mechanically connected to the tractor engine, through a belt or a drive shaft. This allows the tractor engine to transfer its mechanical energy to the generator;
• Energy transformation via magnetic induction : the generator receives mechanical energy from the tractor and transforms it into electrical energy that can be used for electrical equipment, pumps, engines or agricultural equipment.
• Tractor speed adjustment : there is a correlation between the energy generated by the motion of the tractor and the power emitted by the cardan generator. Accelerating or decelerating the tractor can affect the frequency and voltage of the electricity produced.

Equipped with a compound or AVR type current regulator , it requires a minimum value of tractor engine power and input rpm to allow operation; the multiplier with protection will then supply the alternator with the energy necessary to create the electric current.

Cardano generator with AVR

A power generator's AVR works by constantly monitoring the generator's output voltage and adjusting the alternator's magnetic field to keep the output voltage constant, regardless of load demand. This allows you to connect electronic devices sensitive to surges to the cardan generator, preventing voltage variations that could cause malfunctions.

4 pole alternator

Alternators have 2 or 4 poles . The 2 poles are suitable for 3000 rpm engines, while the 4 pole alternators are for 1500 rpm engines.
