IPC PW H90
Three-phase pressure washer

IPC PW-H90 Three-phase hot pressure washer

IPC PW-H90 professional pressure washer built specifically to last over time . For over 50 years IPC has been involved in the design and construction of professional pressure washers and therefore knows how important it is to have a machine capable of working without interruptions . IPC created the PW-H90 to achieve reliability first and foremost , using high quality components.

PW-H90 consumes 7.6 kg/h and is extremely easy to maintain in every part thanks to the innovative layout of the machine which allows easy access to the internal components .

Watch the IPC PW-90 Video

Easy to Use Controls

Pressure and temperature regulation is extremely easy and intuitive thanks to direct access to the internal components and the simplicity of use of the control panel .

• Continuous pressure regulation
  direct access to the pressure regulator makes cleaning operations comfortable
• Temperature regulation
  Temperature adjustment easy to reach and operate via knob on the control panel

Main features

• 1400 RPM asynchronous electric motor , guarantees long life of the mechanical components and does not require maintenance. Equipped with thermal protection
• The low voltage controls guarantee maximum safety for the user
• AP pump with connecting rod and crank system with brass head and ceramic pistons
• High efficiency stainless steel boiler : there is no rust formation. Double spiral steel coil
• Boiler ventilation with independent motor
• Electrical panel protected from splashes of water and dirt thanks to a transparent material cover
• Anti-limescale tray with a capacity of 3.5 L
• Engine pump coupling with elastic joint which guarantees less vibrations, greater reliability and durability of all mechanical components
• Outgoing water temperature of 30÷140°C
• Diesel tank capacity of 30 L
• Detergent tank capacity 16 L
• Tanks integrated into the trolley equipped with plugs for draining and cleaning
• Pressure adjustable from the outside
• Ergonomic handles for easy and comfortable transportation
• 2 pivoting wheels on the back and 2 front wheels make the machine stable and easy to transport
• Control panel complete with engine and burner ignition switch, adjustable thermostat, detergent tap, pressure gauge
• Warning lights: microleaks, diesel level and anti-scale
• Practical hose reel

Safety Devices

The operator can work in any environment and condition always in maximum safety.

Intelligent Total Stop ITS
Turns off the machine temporarily after 30 seconds of inactivity and automatically restarts it when the gun is activated again or turns it off permanently after a period of inactivity

Accessories supplied

• Pistol
• High Pressure Hose 10 m
• Lance
• High Pressure Nozzle

Technical specifications
