Fral FD360TCR FD520TCR
Dehumidifier with Condenser
for Industry Archives
400V - 5.2 ÷6.7 kW - 61÷65 dB
3000÷4300 m³/h - 360÷520 L/ 24 h
External Condenser - Continuous Discharge
Warranty 2 years
14 days to change your mind
Shipped on Pallet
Fral FD360TCR FD520TCR - Dehumidifier with External Condenser
The Fral FD360TCR and Fral FD520TCR dehumidifiers belong to the industrial dehumidifiers with external condenser that allow dehumidification combined with cooling, performing simultaneous control of humidity and temperature. The Fral FD360TCR and Fral FD520TCR dehumidifier is suitable for use in environments where it is necessary to control humidity and temperature.
These Fral dehumidifiers are equipped with a mechanical dehumidifier on board the machine, with a digital thermostat for temperature control.
The Fral FD TCR series dehumidifiers are equipped with a hot gas defrosting system (optional) , with electronic and thermostatic control. They can work up to temperatures close to 0 °C.
How a dehumidifier works
A dehumidifier is a machine that sucks in air and filters it. The air passes through a radiator filled with refrigerant gas . The low temperature condenses the humidity present, collecting the waste liquid in a tank. The Fral dehumidifier recirculates the filtered and humidity-free air through the action of a fan .
Functional specifications
Sturdy structure in galvanized sheet metal
The supporting structure of Fral FD360TCR and Fral FD520TCR It is made up of panels in sturdy hot-dip galvanized sheet metal , painted with epoxy powders . These guarantee high resistance to atmospheric agents and aggressive environments . The panels of this Fral industrial dehumidifier are removable , which allows for quick inspection and maintenance of the internal elements.
Scroll compressor and fixed exhaust
The compressor inside Fral FD360TCR and Fral FD520TCR is of the scroll type, mounted on anti-vibration mounts and equipped with an electric resistance on the casing. The tank is made of anti-corrosion stainless steel; the dehumidifier must be connected to a fixed drain, avoiding the formation of double siphons, using a pipe with a 3/4''F connection to the tank.
Degree of protection
Dehumidifier with IP21 protection, IP44 on request.
External unit
The remote condenser of this Fral dehumidifier is made with Ø 3/8” copper pipes and 0.1 mm thick aluminium fins. The pipes are mechanically rolled into the aluminium fins to increase the heat exchange factor. The geometry of these exchangers allows for a low air side pressure drop value and therefore the possibility of using low-rev fans (with consequent reduction in machine noise). The fan section is made up of helical fans directly coupled to the electric motor with internal thermal protection and equipped with an accident prevention mesh. The motors all have an IP 54 protection rating.
3 speed centrifugal fan
The fan mounted on Fral FD360TCR and Fral FD520TCR is a three-speed centrifugal type with double suction . Made from sturdy galvanized sheet metal blades , the Fral dehumidifier fan is statically and dynamically balanced .
Hot gas defrosting
It allows the use of the dehumidifier in environments with temperatures up to 3°C , it is a special hot gas injection system to speed up the defrosting of ice formed in the evaporator.
Dehumidifier air delivery
The standard delivery of this Fral dehumidifier is placed on the side opposite the intake , but it is possible to request the professional dehumidifier in the Top version - with delivery on the upper side of the machine.
High efficiency washable air filter
Made of polyurethane , the air filter of Fral FD360TCR and Fral FD520TCR is washable and easily replaceable. High efficiency filter .
Microprocessor
Controls the defrost cycles , the compressor timer and the alarm board. The FD240 model, being three-phase , is equipped with phase sequence control. The microprocessor of this dehumidifier is equipped with a 0-10 V output for modulating control (optional) or ON/OFF as standard for external unit control.
Easily visible control panel
Located on the side of the machine. Complies with European regulations.
Optional: Condensate lifting pump
On request.
Yield of Fral FD360TCR and Fral FD520TCR dehumidifiers
Condensed water at different temperatures
Air flow at different back pressures (mc/h)
Fields of application
- Swimming pools
- Archives
- Gyms
- Conservation
- Ironing shops
- Laundries
- Rental
- Hotels
- Industry
Accessories Available - On Request
- Hot GAS defrosting
- Below 0°C Defrost
- Post-heating electric resistors
- Useful head 200 Pa
- Post-heating hot water battery
- 3-way ON/OFF valve kit
- Anti-corrosion painting evaporator
- Removable intake air filter kit for ducted version
- Version with 316 stainless steel body
- BMS control including duct humidity probe
- Monobloc version
- CAREL Remote Display Panel - ACS02.636
Technical Data
| Model | FD360TCR | FD520TCR |
| Power Supply | 400V | 400V |
| Consumption | 5.2 kW | 6.7 kW |
| Nominal Air Flow | 3000 m³/h | 4300 m³/h |
| Max Dehumidification Capacity | 360 L/24 h | 520 L/24 h |
| Max Absorbed Current | 12.5 A | 15.6 A |
| External Unit Flow Rate | 7200 m³/h | 7200 m³/h |
| Noise | 61dB(A) | 65dB(A) |
| Refrigerant | R407c | R407c |
| Condensation Drain Connection | 3/4'' | 3/4'' |
| Relative Humidity T< 30 °C | 45 ÷ 99 % | 45 ÷ 99 % |
| Relative Humidity T 30 ÷ 32 °C | 45 ÷ 90 % | 45 ÷ 90 % |
| Relative Humidity T 32 ÷ 35 °C | 45 ÷ 70 % | 45 ÷ 70 % |
| Temperature | 7 ÷ 35 °C | 7 ÷ 35 °C |
| Average Rated Power Absorbed | 9.2 kW (4 kW resistors) | 10.4 kW (4 kW resistors) |
| Hot Water Heating Capacity (room 27°) | 9 kW (water 60/70 °C) | 12 kW (water 60/70 °C) |
| Mechanical Humidistat | YES | YES |
| External Unit | YES | YES |
| Copper Pipes | 3/8'' | 3/8'' |
| Dimensions | 118 x 72 x 90 cm | 118 x 72 x 90 cm |
| Continuous Discharge | YES | YES |
| Dehumidifier Weight | 150 kg | 170 kg |
| External Unit Weight | 80 kg | 116 kg |
Technical Data
| Model | FD360TCR | FD520TCR |
| Power Supply | 400V | 400V |
| Consumption | 5.2 kW | 6.7 kW |
| Nominal Air Flow | 3000 m³/h | 4300 m³/h |
| Max Dehumidification Capacity | 360 L/24 h | 520 L/24 h |
| Max Absorbed Current | 12.5 A | 15.6 A |
| External Unit Flow Rate | 7200 m³/h | 7200 m³/h |
| Noise | 61dB(A) | 65dB(A) |
| Refrigerant | R407c | R407c |
| Condensation Drain Connection | 3/4'' | 3/4'' |
| Relative Humidity T< 30 °C | 45 ÷ 99 % | 45 ÷ 99 % |
| Relative Humidity T 30 ÷ 32 °C | 45 ÷ 90 % | 45 ÷ 90 % |
| Relative Humidity T 32 ÷ 35 °C | 45 ÷ 70 % | 45 ÷ 70 % |
| Temperature | 7 ÷ 35 °C | 7 ÷ 35 °C |
| Average Rated Power Absorbed | 9.2 kW (4 kW resistors) | 10.4 kW (4 kW resistors) |
| Hot Water Heating Capacity (room 27°) | 9 kW (water 60/70 °C) | 12 kW (water 60/70 °C) |
| Mechanical Humidistat | YES | YES |
| External Unit | YES | YES |
| Copper Pipes | 3/8'' | 3/8'' |
| Dimensions | 118 x 72 x 90 cm | 118 x 72 x 90 cm |
| Continuous Discharge | YES | YES |
| Dehumidifier Weight | 150 kg | 170 kg |
| External Unit Weight | 80 kg | 116 kg |
