Fimap FS80
Compact ride-on sweeper
Battery / Diesel
11520 ÷ 12960 m²/h
Container capacity 370 L
Warranty 2 years
14 days to change your mind
Shipped on Pallet
Fimap FS80 - Industrial Compact Sweeper
The Fimap FS80 series of ride-on compact sweepers are among the most compact industrial sweepers of their kind, becoming the perfect machines for cleaning both large surfaces and narrow or cumbersome passages. The Fimap FS80 series are compact industrial sweepers designed to easily sweep solid debris and light dust on surfaces of up to 30,000 m² , in industrial environments , car parks and campsites .
These Fimap FS80 Industrial Sweepers are characterized by a working width of 80 cm thanks to the central brush with which they are equipped.
The Fimap FS80 ride-on sweepers, together with the same ones in the FS90 and FS110 series which stand out for their relative working width, are born with a box frame built around the central brush and with extremely small dimensions , thus allowing compactness to be combined with great power.
Fimap FS80 is available both in the FS80 B version with 36 V battery (4 hours autonomy) and in the FS80 D version with Diesel operation, which can be selected from the drop-down menu above.
These compact ride-on sweepers are designed to ensure ease of use and operator comfort. The Fimap FS80 are designed down to the smallest detail with a driver's seat accessible from both sides for maximum ease of use even in confined spaces and the dashboard is designed to have all the necessary controls always within reach.
Functional specifications
Functional dashboard like in a car
The Fimap FS80 sweeper models have an automotive-style dashboard , with immediate display of all functions. The newly designed steering is designed to make driving operations extremely comfortable. Furthermore, directly on the dashboard there is a control for activating the electric filter shaker which allows you to always keep the filter clean even during use.
Work up to 4 hours without stopping
The innovative hydraulic system was designed to increase performance and reduce energy consumption by up to 35% compared to the previous model. For the battery-powered FS80 B model (pictured) , there is an increase in performance for work up to 4 hours.
Driving lights
The light from the headlights makes Fimap FS110 sweepers more visible when moving, for greater safety when used in environments where other people are present.
Effective filtration in any condition
The fabric bag filter with a large filtering surface of 7 m² promises long life as well as excellent suction results even where a high quantity of fine dust is present. This filter is easily removable, making it simple to both check its condition and replace it, taking into consideration that if the filter shaker is used regularly, no maintenance will be necessary.
Side Brush
The side brush of this Battery or Diesel Industrial Sweeper retracts in the event of accidental impacts, thus avoiding possible damage and can be adjusted in inclination so as to adapt perfectly to cleaning along the edges.
Main Brush
The height and pressure of the central brush of this Fimap FS80 ride-on sweeper are adjustable via a convenient knob located near the brush itself so as to adapt its position based on wear, thus extending its life cycle.
Big Wheels
The large diameter wheels, in addition to conducting mechanical stress, increase the comfort of the Fimap FS Compact Sweeper and are equipped with hydraulically controlled brakes . Their sturdy support helps to maintain the operating characteristics unaltered.
Adjustable seat
The seat of the Fimap FS80 Battery or Diesel Sweeper is adjustable, allowing you to move the seat closer or further away from the pedals and is also accessible from both sides to ensure maximum ease of use even in narrow corridors or cluttered environments.
Models available
Below are the two Fimap FS80 models available and selectable from the drop-down menu at the top of the page:
- FS80 B - Battery operated
- FS80 D - Diesel
Main features
- Compact ride-on sweeper
- Agile even in narrow passages
- Functional dashboard
- Lighthouses
- Large filtering surface of 7 m²
- To collect solid debris and dust
- Ideal for industry, car parks, camping
- Working Width 80 cm (without side brushes)
- Working width with side brushes 112 cm
Technical data
| Model | FS80 B | FS80 D |
| Power Supply | 36V battery / Hydraulic | Diesel Engine / Hydraulics |
| Battery autonomy | 4 hours | - |
| Motor | - | Perkins 12 HP |
| Hourly Yield | 11520 m²/h | 12960 m²/h |
| Central Brush Working Width | 80cm | 80cm |
| Working Width with Side Brush | 1120 mm | 1120 mm |
| Filtering Surface | 7 m² | 7 m² |
| Forward speed | 0÷8 km/h | 0÷9 km/h |
| Max. slope | 14% | 20% |
| Traction | Yes | Yes |
| Capacity Container with filter/without filter | 190 / 370 L | 190 / 370 L |
| Central Brush | Ø 800 mm | Ø 800 mm |
| Side Brush | Ø 500 mm | Ø 500 mm |
| Exhaust Type | Hydraulic | Hydraulic |
| Load | Front | Front |
| Machine dimensions | 202 x 143 x 113 cm | 202 x 143 x 113 cm |
| Empty weight | 750kg | 730 kg |
Technical data
| Model | FS80 B | FS80 D |
| Power Supply | 36V battery / Hydraulic | Diesel Engine / Hydraulics |
| Battery autonomy | 4 hours | - |
| Motor | - | Perkins 12 HP |
| Hourly Yield | 11520 m²/h | 12960 m²/h |
| Central Brush Working Width | 80cm | 80cm |
| Working Width with Side Brush | 1120 mm | 1120 mm |
| Filtering Surface | 7 m² | 7 m² |
| Forward speed | 0÷8 km/h | 0÷9 km/h |
| Max. slope | 14% | 20% |
| Traction | Yes | Yes |
| Capacity Container with filter/without filter | 190 / 370 L | 190 / 370 L |
| Central Brush | Ø 800 mm | Ø 800 mm |
| Side Brush | Ø 500 mm | Ø 500 mm |
| Exhaust Type | Hydraulic | Hydraulic |
| Load | Front | Front |
| Machine dimensions | 202 x 143 x 113 cm | 202 x 143 x 113 cm |
| Empty weight | 750kg | 730 kg |
