Novamach Electric Hoist
Capacity 3000÷10000 kg

Novamach 400V Electric Hoist for Lifting Loads from 3000 to 10000 kg

The Novamach 400V electric hoist is a professional lifting system designed for loads from 3,000 to 10,000 kg in industry and warehouses. Available in single or dual speed , it features a 3 m chain and cable with a push-button panel , ensuring precise and safe operations even in harsh environments. The IP65 protection on the structure and push-button panel ensures resistance to dust and water.

Available models

Models with chain diameter 11.2 and capacity 3000 kg :

• SG.0.DTS.03001 : single lifting speed 6 m/min
• SG.0.DTS.03002 : double lifting speed 6/2 m/min

Models with chain Ø 11.2 and capacity 5000 kg :

• SG.0.DTS.05002 : double lifting speed 3/3.1 m/min

Models with chain Ø 11.2 and capacity 7500 kg :

• SG.0.DTS.07502 : double lifting speed 2.5/0.85 m/min

Models with chain Ø 11.2 and capacity 10000 kg :

• SG.0.DTS.10002 : double lifting speed 3/1 m/min

Technical specifications

400V operation with a capacity of 3000 to 10000 kg . Adjustable speed from 6 m/min down to 0.6–3 m/min depending on the model. Chain Ø 11.2 mm with 1 to 4 falls, hoist weight from 94 to 329 kg and extra chain weight up to 10.8 kg/m. Power consumption from 3 kW up to 6/3 kW . Compact dimensions and robust construction for stability and reliability in every lift.

Functional specifications

Heavy lifting

Handles loads from 3000 to 10000 kg with precision and safety, ideal for intensive industrial operations.

Single and double speed

Adjustment between constant speed or double speed for quick or gentle lifting depending on the load.

Strong and durable chain

Ø 11.2 mm chain with multiple pulls in the heavier models, guarantees safety and durability even under high loads.

IP65 protection

Structure and control panel protected from dust and water, ensuring long life and reliability of the hoist in harsh environments.

Dimensions

Characteristics

• 400V three-phase electric hoist
• Power from 3 to 6/3 kW
• Capacity from 3000 to 10000 kg
• Adjustable speed from 6 m/min to 0.6-3 m/min

Standard Equipment

• 3 m chain
• 3 m keypad cable
