Helvi SpotCar EVO 4000
Spot Welding Iron Welder

Helvi SpotCar EVO 4000 - Spot Welding 2.5 kVA

The Helvi SpotCar EVO 4000 cod. 99500043 is a spot welder designed for a wide range of industrial and craft applications. This welder works with single-phase voltage 230 V, highly efficient and compact, ideal for a wide range of industrial and craft applications .

This Helvi SpotCar spot welder is equipped with 50% capacity power at 2.5 kVA, with secondary capacity at 13 kVA . It can handle heavy loads while maintaining its energy efficiency.

Supplied with gun and ground cable , accessory kit consisting of: extractor hammer, 10 three-point washers, head for three-point washers, carbon electrode, crushing electrode.

Functional Specifications

Professional Spot Welder

Helvi SpotCar EVO 4000 is a high quality spot welder , ideal for industrial and craft applications that require precise and reliable welding. With its power, advanced electrical protection and compact size, it is an excellent choice for those looking for a reliable and versatile.

Welder with delayed fuse

The electrical protection of Helvi Spot Car is guaranteed by a delayed fuse of type T16 A , which ensures safe operation even in the event of overload or short circuit. In addition, the class H insulation offers greater electrical thermal protection.

The machine is designed to withstand adverse conditions with an IP22S rating, making it resistant to dust and moisture. This ensures long life and reliable performance even in harsh environments.

Types of welding possible with Helvi SpotCar EVO 4000

SPOT WELDERS : Spot welders, electric resistance spot welders or also called pressure spot welders, generate heat at the contact points between two metal parts by electrical resistance. The heat developed by the current is proportional to the electrical resistance of the conductors. Spot welding is generally used to weld steels and is carried out in three phases:

1. The electrodes are brought close to the surface of the parts to be welded and the pressure necessary to compress the parts together is applied. A pre-set current is passed through the electrodes.
2. Welding control is achieved by adjusting the current intensity and the time during which the current passes through the contact point.
3. The electrodes are moved away from the surfaces of the piece, which are thus joined by a small molten and solidified volume. At the point of contact between two metal objects the resistance is greater than that of the metal, therefore the passage of current causes the area near the contact and if the current is high enough, the two objects fuse and therefore weld.

Characteristics

• Spot Welder
• T16 A slow blow fuse
• Power at 60% of 2.5 kVA
• Secondary power 13 kVA
• Insulation class H - Protection IP22S

• THERE IS
• Certification
• EAC
• Single phase
• Conventional Control
• Automotive
• Display
• Spot
• Touch and Weld

Fields of application

• Light industry
• Automotive Industry
• Metalworking industry
• Metal carpentry
• Commercial Vehicle Construction
• Electronics
• Semiconductor sector
• Energy sector

Extra Accessories

•
  Trolley - code 99900194A

HELVI: Italian excellence in welding

Helvi SpA is an Italian company belonging to the Beta group. Based in Sandrigo, in the province of Vicenza, this Italian manufacturing company specializes in industrial welding machines , plasma cutting machines, professional battery chargers and accessories .
