ABAC LN1 A49B 500 T5.5 DOL
Silent Compressor
Frequent Use 598 L/min

ABAC LN1 A49B 500 - T5.5 DOL Silent Compressor - Frequent Use 598 L/min

The Abac LN1 A49B 500 LT Silent compressor with 5.5 HP belt drive is robust and durable , with an A49B pump unit and air flow rate of up to 598 L/min . It is a fixed and silenced compressor , suitable for frequent use in any professional context.

With a 400V three-phase connection and a 500 L tank , this Abac compressor offers very high efficiency and provides a high pressure of 11 bar .

The Abac LN1 A49B 500 LT compressor is designed for frequent use, ensuring reliability and durability over time thanks to its advanced construction techniques and the high-quality components used . Maintenance on this compressor is extremely easy to perform and features an oil level indicator and an easily accessible air filter .

Functional Specifications

500 L Compressor Tank

The ABAC LN1 A49B 500 LT compressor is equipped with a 500 L compressed air tank. The large quantity of air contained in this compressor makes it perfect for use in small and medium-sized garages and workshops.

Silent Operation

The pumping unit of this compressor is contained in a soundproofed case, which allows it not to exceed 69 dB(A) during its operation, ensuring a low acoustic impact in the working environment.

Star-Delta Starter

The Abac LN1 A49B 500 LT compressor is designed with Y/D (star/delta) electric start to allow for a gradual start, reducing wear on internal components and minimizing the impact on the electrical system during start-up. This technological approach reflects Abac's attention to detail in ensuring efficient operation and a long operating life.

ABAC A49B Compressor with Pump Unit

These piston compressors are equipped with a powerful 1400 RPM A49B pump unit. The low operating speed keeps engine temperatures low, ensuring efficiency, high performance, and reliability. ABAC pump units use innovative materials with a low friction coefficient and high wear resistance.

Characteristics

• For intensive and heavy use
• With silencing hood
• 500 litre air compressor
• Fixed without wheels
• Maximum pressure 11 bar
• Air intake capacity 598 litres per minute
• Electric Motor
• Steel tank
• 5.5 HP induction motor
• Low rotation speed: 1400 rpm
• Belt drive - Drive pulley with ventilation fins
• Double front foot
• A49B 2 pumping group
