Annovi Reverberi AR 5670 - Professional Hot Water Pressure Washer
Annovi Reverberi AR 5670 , a single-phase hot water pressure washer ideal for cleaning stubborn dirt and encrustations. Equipped with a reliable single-phase electric motor with thermal protection and a high-performance piston pump with a connecting rod and crank system . The pressure washer has a particularly compact shape and a solid, durable structure . It is equipped with large rubber wheels for easy movement, and there are also supports for conveniently storing the lance and hose. The machine guarantees maximum reliability thanks to the top-quality components it is built with, such as the automatic by-pass valve with zero pressure in the pump head.
The AR 5670 pressure washer is equipped with a vertical stainless steel boiler with a refractory cement bottom and double coil. It is diesel-powered and uses a spiral burner cooling system powered by an independent electric motor. The water temperature can reach 90°C .
The Annovi Reverberi AR 5670 uses an 8 L diesel tank with a drain plug and offers a built-in detergent suction system. To ensure greater reliability, it features water and diesel filters , a safety pressure switch to ensure the boiler shuts off in the event of a water shortage, and a delay card for shutting it off. A thermostat for temperature regulation and a pressure regulation system are also included.
Self-priming function
A self-priming pump is designed to draw water from an external source (such as a tank, drum, or container) without requiring water to be forced into the pump by initial pressure. This makes the pressure washer more versatile, allowing it to operate even without a direct connection to a pressurized water supply, such as when a tap isn't available, or to use alternative water sources such as tanks and wells.
Technical specifications
- Hot water
- Induction motor
- Connecting rod pump
- IPX5-S1 water resistance
- Brass head
- Total Stop System Timed
HPV-O pump
- 3-piston pump in tempered stainless steel with ceramic coating with connecting rod-crank system, brass head;
- Automatic safety valve with pressure relief in the pump head;
- Single-phase induction electric motor with thermal protection;
- Remote pressure washer total shutdown system;
- Water suction from tank with self-priming function.
Characteristics
- Compact structure
- Transport wheels
- Lance and hose supports
- Hot water up to 90°C
- Piston pump with brass head
- Automatic bypass valve
- Safety pressure switch
- Vertical stainless steel boiler
- Boiler shutdown delay card
- Pressure regulation
- 8 L diesel tank with drain plug
- Thermostat
- Detergent suction
- Water filter and diesel filter
- 5m electric cable
Equipment
- Professional pistol
- Professional steel lance
- Nozzle
- 10 m high pressure hose
