BIEMMEDUE TH 15 30 40
Fixed Vacuum Cleaner
230 ÷ 400V - 1.1 ÷ 3 kW
75 ÷ 97 L / s - 50 L
Shake Filter
Biemmedue TH 15 30 40 - Fixed Industrial Vacuum Cleaner
Biemmedue vacuum cleaners are essential in environments where static electricity may be present, such as in the presence of flour, cement, ceramic dust, synthetic fabrics, etc. causing sparks that lead to combustion and explosion, providing a safer and more comfortable working environment.
Biemmedue vacuum cleaners are recommended for use in the presence of hot particles such as cleaning and maintenance of ovens, fireplaces, furnaces, etc. The special hose and accessories can withstand up to 90 ° C. All the elements inside the vacuum cleaner that come into contact with the hot sucked particles are built to withstand high temperatures. The use of the oven kit allows you to clean ovens with temperatures up to 400 ° C.Biemmedue TH fixed industrial vacuum cleaner designed for continuous work , equipped with a powerful turbine motor built according to the particular principle of side channels: the sucked air, forced to follow a spiral path by means of a particular impeller, is subjected to repeated accelerations , which allow to reach a high pressure and vacuum value. The impeller is mounted directly on the motor shaft and all rotating parts are dynamically balanced, thus obtaining an absolute absence of vibrations .
Main features
- Fixed vacuum cleaners for continuous work
- Antistatic
- Recommended for use in the presence of hot particles up to 90 ° C
- Suitable for removing dust and solid materials from work surfaces
- Normally installed on board production machines
- It can also be easily transported and moved thanks to the optional wheels with brakes
- Powerful motor / turbine unit that allows uninterrupted use without particular maintenance
- Manual filter shaker (automatic available on request)
- Various filters available for different applications
Biemmedue TH Series is compatible with filters:
Standard Equipment
- Polyester filter
- Cartridge filter
- Flexible hose Ø 40 mm
- Flat Lance Ø 40 mm
Equipment on request
Biemmedue vacuum cleaners can be requested with certain precautions that allow use for special applications:
- Use in static electricity environments
- Use in the presence of hot particles
These machines also offer a wide range of accessories for any eventuality: View PDF
Technical data
| TH 15 | TH 30 | TH 40 | |
| Supply | 230V 50 / 60Hz | 230V 50 / 60Hz | 400V 50 / 60Hz |
| Nominal Power Max | 1100 W | 2200 W | 3000 W |
| Air flow | 75 L / s | 97 L / s | 97 L / s |
| Depression Max | 225 mbar | 314 mbar | 314 mbar |
| Container Capacity | 50 L | 50 L | 50 L |
| Cleaning the Filters | Manual | Manual | Manual |
| Barrel material | INOX | INOX | INOX |
| Filtering surface | 5000 cm² | 5000 cm² | 5000 cm² |
| Predisposition of antistatic protection | YES | YES | YES |
| Heat preparation | YES | YES | YES |
| Dimensions | 40 x 82 x 95 cm | 40 x 82 x 95 cm | 40 x 82 x 95 cm |
| Weight | 50 Kg | 50 Kg | 50 Kg |
Technical data
| TH 15 | TH 30 | TH 40 | |
| Supply | 230V 50 / 60Hz | 230V 50 / 60Hz | 400V 50 / 60Hz |
| Nominal Power Max | 1100 W | 2200 W | 3000 W |
| Air flow | 75 L / s | 97 L / s | 97 L / s |
| Depression Max | 225 mbar | 314 mbar | 314 mbar |
| Container Capacity | 50 L | 50 L | 50 L |
| Cleaning the Filters | Manual | Manual | Manual |
| Barrel material | INOX | INOX | INOX |
| Filtering surface | 5000 cm² | 5000 cm² | 5000 cm² |
| Predisposition of antistatic protection | YES | YES | YES |
| Heat preparation | YES | YES | YES |
| Dimensions | 40 x 82 x 95 cm | 40 x 82 x 95 cm | 40 x 82 x 95 cm |
| Weight | 50 Kg | 50 Kg | 50 Kg |
