Munters GA30
Hanging Hot Air Generator 1700 m³/h

Munters GA30 - Professional Hanging Hot Air Generator 1700 m³/h

Munters GA30 is a suspended hot air generator designed to provide powerful and efficient heating in large livestock farms and greenhouses , ensuring optimal conditions for growth and well-being and providing heat to areas up to 1700 m³/h . Thanks to its versatility, it is also ideal for heating large industrial spaces . Powered by LPG gas, the Munters GA30 guarantees excellent performance, simple and immediate installation and use in complete safety.

Munters is a global leader in the development and manufacturing of energy-efficient air conditioning systems.
for the growth and development of agricultural applications.

Technical Specifications

This Munters wall-mounted hot air generator is made of stainless steel , designed to ensure a long life even in humid environments. The electrical components are housed in an IP54- rated casing, making it resistant to dust and splashes of water.

The air flow of GA30 is 1700 m³/h , with a 1.5 mm nozzle. The device works with LPG gas, an operating pressure of 0.7 bar . and a variable consumption between 1.75 and 2.51 kg/h . This hanging heater has a thermal power that varies from 25 to 36 kW , equivalent to 21,500-30,960 kcal/h .

This single-phase 230V generator with 110W 4.5A power is designed to operate at altitudes between 0 and 1000 m .

Functional Specifications

The GA30 hot air generator is designed for professional and industrial applications, such as intensive agriculture , livestock farming and greenhouses . It works on the principle of direct combustion heating , where the air passes through a combustion chamber that houses the burner, allowing the conversion of 100% of the fuel into heat.

To ensure safety , the generator is equipped with a double solenoid valve that regulates the opening and closing of the gas supply, preventing leaks in the event of a fault. In addition, a pressure sensor monitors the air flow and interrupts the gas supply in the event of an obstruction, avoiding the risk of overheating.

The device comes fully assembled, with an electric cable and a gas connection hose with pressure regulator, ready for use.

Upon request, a mechanical or electronic thermostat is available for more precise heating control.

• A = 645 mm
• B = 532 mm
• C = 440 mm
• D = 370 mm

Fields of Application

• Farms
• Agriculture
• Industry

Characteristics

• Single phase
• Direct combustion
• Nominal thermal power 25 - 36 kW
• Maximum gas consumption 2,513 kg/h
• Gas pressure 0.7 bar
• Air flow 1700 m³/h
• Electrical power 110 W
• Weight 15 Kg
• Dimensions 64.5 x 53.2 x 44 cm
• Built-in LPG burner
• Double solenoid valve
• Pressure sensor
• Electric cable
• Gas connection pipe
• Pressure regulator
• Mechanical or electronic thermostat (optional)
